Schematics
Printed in U.S.A. 193 50940411/G0219
RT250 Connector / Splice Locations Index
F13 N/A 199
CAN Terminating Resistor / 120
Ohms
F14 10 199 Tail Lights, Backup Alarm, Radio
F15 30 199 ECU Constant Power F16 30 200 HVAC Relay
F17 10 200 Horn Relay F18 10 196 Ignition
F19 3 210 Radio ATO 1 30 205 Power-A-Tach V-Battery
L1 N/A 198
CAN Terminating Resistor / 120
Ohms
L2 N/A 197
CAN Terminating Resistor / 120
Ohms
Table 59: RT250 Fuses / Resistors
Fuse Amp
Schematic
Page
Protected Circuit / Notes Fuse Amp
Schematic
Page
Protected Circuit / Notes
Table 60: RT250 Connector Names / Schematics Locations
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
C1 196 C2 211 C3 207 C4 207 C5 202
C6 202 C7 202 C8 202 C9 201 C10 201
C11 203 C12 202 C13 203 C14 205 C15 203
C16 202 C17 203 C18 205 C19 202 C20 202
C21 204 C22 201 C23 201 C24 201 C25 205
C26 N/A C27 210 C28 210 C29 206 C30 210
C31 210 C32 196 C33 207 C34 210 C35 N/A
C36 208 C37 207 C38 210 C39 N/A C40 N/A
C41 N/A C42 210 C43 N/A C44 N/A C45 206
C46 N/A C47 N/A C48 209 C49 N/A C50 N/A
C51 N/A C52 N/A C53 196 C54 N/A C55 N/A
C56 N/A C57 N/A C58 N/A C59 N/A C60 201
C61 N/A C62 206 C63 N/A C64 196 C65 197
C66 198 C67 201 C68 206 C69 206 C70 206
C71 205 C72 205 C73 205 C74 211 C75 206
C76 206 C77 210 C78 208 C79 208 C80 210
C81 207 C82 204 C83 196 C84 210 C85 211
C86 211 C87 211 C88 204 C89 204 C90
196, 199,
202, 203,
204, 205,
206, 207,
208, 210,
211,212
C91 209 C92 208 C93 197 C94 208 C95 197
C96 202 C97 202 C98 N/A C99 201 C100 201
C101 203 C102 N/A C103 212 C104 N/A C105 N/A
C106 N/A C107 196 C108 211 C109 200 C110 206
C111 207 C112 208 C113 208 C114 209 C115 207
C116 207 C117 207 C118 207 C119 209 C120 206
C121 205 C122 210 C123 210 C124 205 C125 203
