Gehl RT210 User Manual

Controls
50940411/G0219 58 Printed in U.S.A.
Joystick Control Sensitivity
The sensitivity of the ISO drive controls can be
configured to be more or less aggressive/immediate.
Five levels of control sensitivity are available.
Configuring Control Sensitivity
1. Hold down the interface button (Z, Fig. 16) on
the multi-function display until the configura-
tion selection screen (Fig. 17) displays.
2. Press and release the interface button until the
selection caret points to the / control
sensitivity selection (Y, Fig. 17). Press and hold
the interface button until the Control Sensitivity
Selection screen (Fig. 18) displays.
3. Press and release the interface button as required
to select the desired level of control sensitivity
(Fig. 18). Five levels of control sensitivity are
available.
Move the selection caret toward the top of the
screen (V [ ]) for more aggressive and
immediate control sensitivity; move the selection
caret toward the bottom of the screen (X [ ])
for less aggressive and more relaxed control
sensitivity.
Press and hold the interface button for 5 seconds
to save control sensitivity configuration changes.
4. Press and release the interface button until the
selection caret points to the “EXIT” selection
(W, Fig. 35).
5. Press and hold the interface button until the
home status screen displays. The currently
selected control sensitivity is now activated.
Fig. 16 – Multi-Function Display Interface Button
Z
Fig. 17 – Control Sensitivity Configuration
Selection
Y
Fig. 18 – Control Sensitivity Selection Screen
V
More
Aggressive/
Immediate
Less
Aggressive/
More Relaxed
X
Fig. 19 – Exit Configuration Mode
W

Gehl RT210 Specifications

General

Rated Operating Capacity	2, 100 lbs
Engine Make	Yanmar
Tipping Load	6000 lbs
Displacement	202 cu in
Hydraulic Pressure	3335 psi
Width	72 in
