Controls
50940411/G0219 68 Printed in U.S.A.
Battery Disconnect Switch
(Option)
Before the engine can be started, the battery
disconnect switch must be in the “on” position. The
battery disconnect switch (A, Fig. 40) is located
inside the storage box at the back left corner of the
machine.
Open the storage box using key (D) supplied with
the ignition key.
To disconnect the battery from the electrical
system and disable all electrical functions: Turn
the switch counter-clockwise to the “OFF” position.
To connect the battery to the electrical system
and enable all electrical functions: Turn the switch
clockwise to the “ON” position.
Windshield Wipers/Washer
Wiper/Washer Control
Press bottom (A, Fig. 41) of wiper switch (C) to
activate the wipers. Press and release top (B) of
wiper switch (C) to turn the wipers off.
NOTE:
Indicator (D) is on when the wipers are
activated.
Push and hold top (B) of wiper switch (C) to
activate the washer spray. Release the button to stop
the spray.
to
Washer Fluid Reservoir
See “Windshield Washer Reservoir” on page 161
for windshield washer reservoir location and filling
information.
Fig. 40 – Battery Disconnect Switch
A
D
Fig. 41 – Wiper/Washer Switch
C
A
B
D
Front Wiper/
Washer Switch
Rear Wiper/
Washer Switch
To Next Page
