Gehl RT210 User Manual

Schematics
50940411/G0219 194 Printed in U.S.A.
C126 211 C127 199, 206, 210 C128 212 C129 212 C130 212
C131 197 C132 209 C133 N/A C134 N/A C135 N/A
C136 N/A C137 N/A C138 N/A C139 209 C140 N/A
C141 N/A C142
196, 206,
207, 208,
210, 211
C143 199, 207 C144 N/A C145 N/A
C146 196 C147 205 C148 N/A C149 N/A C150 210
C151 207 C152 197 C153 197 C154 196, 199, 200 C155 196
C156 N/A C157 N/A C158 N/A C159 N/A C160 209
C161 N/A C162 N/A C163 N/A C164 N/A C165 N/A
C166 198 C167 197 C168 196 C169 N/A C170 N/A
C171 N/A C172 N/A C173 N/A C174 196 C175 N/A
C176 209 C177 209 C178A 209 C178B 209 C179 196
C180 N/A C181 N/A C182 197 C183 N/A C184 N/A
C185 196 C186 205 C187 197 C188 N/A C189 N/A
C190 197 C191 196 C192 196
Table 61: RT250 Splice Locations and Functions
Name
Schematic
Page
Function Name
Schematic
Page
Function
SPL1 207 Rear Door Ground SPL2 207 Rear Door Ground
SPL3 208 Wiper Ground SPL4 207 Rear Work Light Power
SPL5 205 High-Flow Reverse Power SPL6 207 Rear Door Alarm Power
SPL7 211 Cab Power SPL8 204 CAN Low
SPL9 211 CAN High SPL10 204 CAN Low
SPL11 204 CAN High SPL12 204 Cab Control Ground
SPL13 204 Cab Control Ground SPL14 208 Cab Ground
SPL15 210 Cab Ground SPL16 204 Cab Control Ground
SPL17 205 Cab Ground SPL18 211 Seat Power
SPL19 208 ROPS Ground SPL20 202 Drive Pump Power
SPL21 198 Throttle Ground SPL22 208 Wiper Power
SPL23 207 ROPS Work Light Power SPL24 199 Radio/Beacon Power
SPL25 207 ROPS Ground SPL26 206 HVAC High Speed Power
SPL29 202 Swash Plate Sensor Power SPL30 202 Swash Plate Sensor Ground
SPL31 201 Chassis Hydro Ground SPL32 201 Chassis Hydro Ground
SPL33 212 Chassis Ground SPL35 201 Float Solenoid Power
SPL36 202 Drive Pump Power SPL37 202 Controller #2 Power
SPL40 206 A/C Power SPL41 206 HVAC High Speed Power
SPL42 203 CAN Low SPL43 203 CAN High
SPL44 201 Park Brake Power SPL45 212 Chassis Ground
SPL46 209 EU Lighting Power SPL47 212 Chassis Ground
SPL49 196 Main Switched Power SPL50 199 Main Switched Power
SPL52 198 Sensor Ground SPL53 204 Throttle Power
Table 60: RT250 Connector Names / Schematics Locations
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page

Gehl RT210 Specifications

General

Rated Operating Capacity	2, 100 lbs
Engine Make	Yanmar
Tipping Load	6000 lbs
Displacement	202 cu in
Hydraulic Pressure	3335 psi
Width	72 in
