Gehl RT210 User Manual

Schematics
Printed in U.S.A. 215 50940411/G0219
Table 65: RT175 / RT210 Connector Names / Splice Locations and Functions
Name
Schematic
Page
Function Name
Schematic
Page
Function
SPL1 228 Rear Door Ground SPL2 228 Rear Door Ground
SPL3 229 Wiper Ground SPL4 228 Rear Work Light Power
SPL5 226 HF Aux Rev. Power SPL6 228 Rear Door Power
SPL7 232 Cab Power SPL8 225 CAN Low
SPL9 232 CAN High SPL10 225 CAN Low
SPL11 225 CAN High SPL12 225 Cab Control Ground
SPL13 225 Cab Control Ground SPL14 229 Cab Ground
SPL15 231 Cab Ground SPL16 225 Cab Control Ground
SPL17 226 Cab Ground SPL18 232 Seat Power
SPL19 229 ROPS Ground SPL20 223 Drive Pump Power
SPL21 219 DPF Sensor Ground SPL22 229 Wiper Power
SPL23 228 ROPS Work Light Power SPL24 228 Radio/Beacon Power
SPL25 228 ROPS Ground SPL26 227 HVAC High Spd Power
SPL27 219 Power Splice SPL28 216 Main Power
SPL29 223 Swash Sensor Power SPL30 223 Swash Sensor Ground
SPL31 222 Chassis HYD Ground SPL32 222 Chassis HYD Ground
SPL33 233 Chassis Ground SPL35 222 Float Solenoid Power
SPL36 223 Drive Pump Power SPL37 223 Controller #2 Power
SPL39 233 Chassis Ground SPL40 227 A/C Power
SPL41 227 HVAC High Spd Power SPL42 224 CAN Low
SPL43 224 CAN High SPL44 222 Park Brake Power
SPL45 233/ Chassis Ground SPL46 229 Flasher Power
SPL47 233 Chassis Ground SPL49 217 Main Switched Power
SPL50 217 Main Switched Power SPL51 219 Oil Pressure Switch
SPL54 216 Main Switched Power SPL56 223 Tilt Solenoid Power
SPL57 217 Cab & ROPS Power SPL58 230 EU Running Light
SPL59 230 EU High Beam SPL60 230 EU Low Beam
SPL61 230 EU Flasher SPL62 230 EU Brake Light
SPL63 233 ROPS Ground SPL64 225 CAN High
SPL65 225 CAN Low SPL66 230 EU Rear Ground
SPL71 233 Chassis Ground SPL74 217 Power Splice
SPL75 217 Power Splice SPL77 219 HPP Pump CAN
SPL78 217 ECU Power Splice SPL79 219 HPP Pump CAN
SPL80 216 Ignition Switched Power SPL82 226 HF Aux FWD Power
SPL84 217 Power Splice SPL85 217 Power Splice
SPL86 217 Power Splice SPL88 217 Power Splice
SPL89 217 Power Splice SPL90 230 EU Lighting Power
SPL91 230 EU Lighting Ground SPL97 230 EU Lighting Switched Power
SPL98 227 HVAC Control Power SPL99 233 Chassis Ground

Gehl RT210 Specifications

General

Rated Operating Capacity	2, 100 lbs
Engine Make	Yanmar
Tipping Load	6000 lbs
Displacement	202 cu in
Hydraulic Pressure	3335 psi
Width	72 in
