Schematics
Printed in U.S.A. 235 50940411/G0219
RT175 (Serial Numbers 10951 - 811000), RT210 (Serial Numbers 21201 - 921000) Con-
nector / Splice Locations Index
Table 67: RT175 / RT210 with interim Tier 4 Engines - Fuses / Resistors
Fuse Amp
Schematic
Page
Protected Circuit / Notes Fuse Amp
Schematic
Page
Protected Circuit / Notes
F1 10 248
Drive Logic Control, Tilt
(Controller 2)
F2 10 241
Interlocks, 2-Speed, Float,
Hydraglide, High Flow Aux
(Controller 3)
F3 20 241
Lift, Standard Aux. Hydraulics
(Controller 1)
F4 10 241 Park Brake Light, Power-A-Tach
F6 10 241
Display, Joysticks, Seat and Door
Switches
F7 10 241 Fuel Pump, Power Splice
F8 20 247 HVAC Condenser F9 20 241 Work Lights
F10 10 248 Auxiliary Power Outlets F11 20 241 Wipers
F12 N/A 239
Oil Pressure Switch Resistor / 120
Ohms
F13 15 241 Track Tension, Self-Level
F14 20 241 EU Headlights F15 10 241 Rear Door Lights, Radio
F16 N/A 244
CAN-Bus Terminating Resistor /
120 Ohms
F17 3 249 Radio
Maxi1 60 238 Starter Solenoid Maxi2 80 238
Power Relay, Ignition Switch, Dome
Lights
Maxi3 40 247 HVAC Relay Maxi 4 60 238 Engine Pre-Heater
ATO1 30 246 Power-A-Tach V-Battery
Table 68: RT175 / RT210 with interim Tier 4 Engines - Connector Names / Schematics Locations
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
Name
Schematic
Page
C001 249 C1 238 C2 252 C3 248 C4 248
C5 243 C6 243 C7 245 C8 245 C9 242
C10 242 C11 244 C12 243 C13 244 C14 246
C15 244 C16 243 C17 244 C18 246 C19 243
C20 243 C21 245 C22 242 C23 242 C24 242
C25 246 C26 250 C27 250 C28 250 C29 247
C30 250 C31 250 C33 250 C36 249 C37 250
C38 250 C41 239 C42 248 C43 239 C44 239
C45 247 C46 238 C47 239 C48 251 C49 239
C50 239 C51 238, 247 C53 238 C60 242 C61 239
C62 247 C63 238 C65 239 C66 240 C67 242
C68 247 C69 247 C70 247, 251 C71 246 C72 246
C73 246 C74 252 C75 247 C76 247 C77 248
C78 249 C79 249 C80 248 C81 250 C82 245
C83 238 C84 252 C85 252 C86 252 C87 252
