Table 3: Dimensions
RT175 RT210 RT250
A Overall Operating Height (fully raised) 4267 mm (168.0 in.)
B Height to Hinge Pin (fully raised) 3251 mm (128.0 in.)
C Reach (fully raised) 876 mm (34.5 in.)
D Dump Angle (fully raised) 40.2° 39.0° 41°
E Dump Height (fully raised) 2489 mm (98.0 in.)
F Maximum Rollback Angle (fully raised) 102.5°
G Overall Height at ROPS 2103 mm (83.0 in.) 2111 mm (83.1 in.)
H
Overall Length (with bucket and standard
counterweight)
3658 mm (144.0 in.) 3762 mm (148.1 in.) 4008 mm (157.8 in.)
I Overall Length (w/out bucket) 2814 mm (110.8 in.) 2959 mm (116.5 in.) 3221 mm (126.8 in.)
J Specified Height 1715 mm (67.5 in.) 1720 mm (67.7 in.)
K Reach (at specified height) 790 mm (31.1 in.) 795 mm (31.3 in.)
L Dump Angle (at specified height) 75.0.°
M Maximum Rollback Angle (at ground) 30.0°
N Carry Position 208 mm (8.2 in.)
O Max. Rollback Angle (at carry position) 31.6°
P Digging Position (+ above / -below ground) 23 mm (0.9 in.) 16 mm (0.6 in.) 13 mm (0.5 in.)
Q Angle of Departure (standard counterweight) 30.4° 29.2° 25.0°
R Ground Clearance 333 mm (13.1 in.) 335 mm (13.2 in.)
S Track Gage 1313 mm (51.7 in.)
T Track Shoe Width 320 mm (12.6 in.) 450 mm (17.7 in.)
U Crawler Base 1392 mm (54.8 in.) 1483 mm (58.4 in.) 1562 mm (61.5 in.)
V Overall Width (w/out bucket 1636 mm (64.4 in.) 1765 mm (69.5 in.)
W Bucket Width 1674 mm (65.9 in.) 1877 mm (73.9 in.) 2131 mm (83.9 in.)
X Front Clearance Radius (with bucket) 2322 mm (91.4 in.) 2403 mm (94.6 in.) 2499 mm (98.4 in.)
Y Front Clearance Radius (w/out bucket) 1448 mm (57.0 in.) 1504 mm (59.2 in.) 1544 mm (60.8 in.)
Z
Rear Clearance Radius (standard
counterweight)
1577 mm (62.1 in.) 1641 mm (64.6 in.) 1796 mm (70.7 in.)
Maximum Rollback at Specified Height 66.8°
Angle of Approach 90°
Grouser Height 25.4 mm (1.0 in.)
