8.3 Alarm profile
Shows all applicable alarms for the currently
selected ventilation mode (MAN or AUTO)
along with their set upper and lower limits.
1 2
4
6
3
5
1. Ventilator alarms
2. Gas alarms
3. Alarm auto set
4. Mute Apnea alarms
5. HLM mode (CPB mode)
6. Alarm sound level
For a detailed description, see Chapter 10,
page .
8.4 Start/End case
8.4.1 Start case
Starts a new patient case and activates the
preset gas and ventilation settings depending
on the setting of the AUTO/MAN ventilation
switch.
The agent concentration setting is only
accessible during an ongoing patient case and
must be manually set from its default position;
OFF.
8.4.2 End case
Provides various options for completing a
patient case.
The following is displayed:
1
2
3
4
1. Go to Standby
2. Go to Standby and return to startup
configuration
3. Save patient trends and clinical logs to
USB memory
4. Delete patient log and trend data
FLOW-i 4.2, User's Manual
157
