SpectroEye™12
1
1 • Set-up
Control wheel
Instrument firmware functions, menu options or measurement
windows can be selected using this wheel.
The display
The display is easy to view and has graphic capabilities.
It displays the available functions and measurement results.
Measurement module
The moving measurement head contains the optics, the built-in
white reference and automatic filter wheel, in a high precision
multiple use measurement module.
Targeting aperture
The targeting aperture is fully visible. Quick and accurate
positioning is simple even with small color patches
and color bars.
Data port
The SpectroEye is equipped with a multi-function port.
Data exchange, protocol management and battery charging
are all performed by the same interface.
Serial plate
The certification plate gives the main specifications of the
SpectroEye at a glance. The serial number of the instrument
is very important, and must be quoted when contacting
GretagMacbeth either by phone or via the Internet.
1.1.3 SpectroEye functional elements
Measurement pad
Pressing lightly on this pad starts a measurement or selects
the menu option highlighted on the display.
