SpectroEye™44

2 • Use

○○○○○○○○○○○○○○○○○○○○○○○○○

○○○○○○○○○○○○○○○○○○○○○○○○

2.4.2 Series measurement

In Series measurement it is possible to save in the SpectroEye’s

memory, several references as Series. The measured sample

is either automatically or manually assigned to the related

reference. While the reference values are kept in memory

until they are deleted by the operator, the samples are over-

written for each new measurement.

To operate in Series measurement is described here using

the color measurement function of the CIELAB system.

To understand this procedure the Single measurement

section (2.4.1) should already have been reviewed.

2.4.2.1 Creating a series of references

From main menu select:

Series measurement > New measurement > New reference

A special Reference measurement window appears. This is the

window used to exclusively create and process the references.

First, check your measurement conditions. Next measure the

desired reference. As soon as the measurement value is taken,

a reference name assigned by SpectroEye appears, and the

Reference parameters icon is displayed in the symbol bar.

Select the icon to change the color name and to define the

tolerances for subsequent Pass/Fail evaluation.

To change the name, cancelling that proposed, use the Name:

menu item, and enter a new name.

Here you can define both the density and colorimetric tolerances

which will be used for subsequent analysis. The tolerance values

proposed here are taken from Settings in the User defined >

Standard measurement > Pass/Fail tolerance menu.

Whether these values are taken without changes or they are

modified, the settings are always saved together with the

corresponding reference. The default settings are then kept

unchanged and they will be reproposed as standard settings

for each new reference.
