GretagMacbeth Spectroeye - Additional Processing and Deleting of References; Measurement of Samples

SpectroEye™ 45
2
2 • Use
○○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Input your own settings and exit the reference window with
Continue. The measured reference is included in the New
series menu and you are requested to define another original
through New reference. Repeat the operation described above
for all references.
2.4.2.2 Additional processing and deleting of references
After assigning the last reference, a list of all available references
appears in the New series menu. If, during a reference definition,
either you forgot to enter the tolerance values, you wish to repeat
the measurement or you wish to change the name, just select
the corresponding reference menu item. Then the reference
window is selected, where you may perform the changes.
To cancel a reference from the memory, select Delete reference
from the New series menu, then select the reference name and
confirm with Yes.
Both the additional processing and the reference cancellation
may also be performed inside the measurement window.
You may switch to this window, to perform changes, using
the Modify reference icon inside the reference window.
2.4.2.3 Measurement of samples
To measure samples, select the Continue item within the
New series menu. You will switch to the measurement window.
Here, the measurement window is used primarily to measure
and analyse samples.
Measure a sample. As soon as the measurement value is
taken, this is automatically assigned to a defined reference,
the reference name is displayed and a Pass/Fail evaluation is
performed. With the measurement of a new sample the previous
measurement value is overwritten, and a reference assignment
as well as a Pass/Fail evaluation are performed.
