GretagMacbeth Spectroeye - User Defined Settings; Measurement Set-Up

SpectroEye™62
2
2 • Use
Here you should select the most
frequently used settings in normal
operation. In this way it is possible
to guarantee a consistency to the
color measurement, which should
only be modified occasionally to
meet the application requirements.
○○○○○○○○○○○○○○○○○○○○○○○○○
○○○○○○○○○○○○○○○○○○○○
2.6.2 User defined settings
First select the following from the main menu
Settings > User defined
Here you can define the following settings:
• Measurement set-up
• Function Access
• Printer
• Turn display
• Language
2.6.2.1 Measurement set-up
Settings of Measurement set-up menu are considered the
default ones. They are always taken as basic settings when
you are working with a Single measurement or when you create
a Series measurement or Jobs.
To define these basic settings, starting from the main menu
you must select
Settings > User defined > Measurement set-up
and then:
• Measurement conditions
All settings of the Measurement conditions menu should
be made with great care as they affect the measurement
results. They can be checked on the symbol bar of
the measurement window and can be changed to meet
the application requirements, at any time.
The measurement conditions include:
- Physical filter
Determine if the measurement must be performed using
a physical filter.
The following filter settings are available
-No -> without filter
- Pol -> polarisation filter
- D65 -> Average North Sky daylight
- UVCut -> UV suppression
○○○○○○○○○○○○○○○○○○○○○○○○○
If you don‘t know which filter must
be used select NO for spectral
measurements and POL for
densitometric measurements.
