SpectroEye™18
1
1 • Set-up
Take care to use the right
connecting cable!
Take care to use the right
connecting cable!
1.2.3.7 Connecting to the Ethernet
Connection to the Ethernet via hub
1. Insert connecting cable 36.64.31 into the SpectroEye
data port.
2. Insert the other end of the connecting cable into the
GretagMacbeth instrument socket of the communications
adapter.
3. Insert the Ethernet cable into the Ethernet = socket on
the communications adapter.
Connection to the Ethernet directly on computer
1. Insert connecting cable 36.64.31 into the SpectroEye
data port.
2. Insert the other end of the connecting cable into the
GretagMacbeth instrument socket of the communications
adapter.
3. Insert the Ethernet cable into the Ethernet X socket on
the communications adapter.
1.3 Transport
For transporting the SpectroEye, always use the original case
and secure the instrument with the transport protection.
To activate the transport protection, select the following from
main menu:
Settings > General > Transport protection > Lock transport
protection
and confirm with Yes.
To remove the transport protection, simply enter the
number 259.
GretagMacbeth declines all
responsibility for damage to the
SpectroEye during transport caused
by inadequate packaging and
protection.
