Model 574 Programmable Counting System (PCS)
46 - GSE Scale Systems
PARAMETER # SELECTION DESCRIPTION
P5112.8Macro 8 Macro 8 will execute when
setpoint activates.
P5112.9Macro 9 Macro 9 will execute when
setpoint activates.
P5112.º Macro 10 Macro 10 will execute when
setpoint activates.
P5112.º Macro 11 Macro 11 will execute when
setpoint activates.
P5112.º Macro 12 Macro 12 will execute when
setpoint activates.
P5112.º Macro 13 Macro 13 will execute when
setpoint activates.
P5112.º Macro 14 Macro 14 will execute when
setpoint activates.
P5112.º Macro 15 Macro 15 will execute when
setpoint activates.
P5112.º Macro * none No macro will execute when
setpoint activates.
P5113.0 Mot'n * Ign'd Motion ignored (motion has no
effect).
P5113.1 Inhib Setpoint state not changed if
motion present.
P5114.0 Basis * new # Lower Activate Target value is
a specific value.
P5114.1 % val The entered Lower Activate
value for this setpoint is a %
multiplier of another variable
to be specified.
P5114.2 diff The entered Lower Activate
value for this setpoint is
subtracted from another to be
specified variable.
P5115. AL * XXX.XXX Activate value (Lower limit if
P5110 is set to between or
outside). Note if P5114 is " %
val " or is " diff " then this
value is a percentage of or
difference of another value.
P5116.0 Based Var # Based on one of ten variables,
P80 - P89, which ar accessible
during normal operation.
P5116.1 SPt 1 Based on one of setpoint #1's
values.
