GSE Scale Systems - 47
Chapter 4 Parameter Setup (Advanced) Technical Reference Manual
PARAMETER # SELECTION DESCRIPTION
SECTION - 4.6
P5116.2 SPt 2 Based on one of setpoint #2's
thru thru values.
P5116.º SPt32 Based on one of setpoint #32's
values.
The set of available choices for P5117 depends upon the selection made in P5116. If set for P5116.0 you will
be able to select from the set immediately below: if set for any other selection, you will be restricted to the
second set of selections below.
P5117.0 Value Var#0 Based on variable #0
P5117.1 Var#1 Based on variable #1
P5117.2 Var#2 Based on variable #2
thru
P5117.9 Var#9 Based on variable #9
OR
P5117.0 Value AL Based on the lower activation
parameter.
P5117.1 AU Based on the upper activation
parameter.
P5117.2 DL Based on the lower de-
activation parameter.
P5117.3 DU Based on the upper de-
activation parameter
P5118.0 Basis new # The Upper Activate Target
value is a specific value
P5118.1 % val The entered Upper Activate
value for this
setpoint is a % multiplier of
another (to be specified)
variable
P5118.2 diff The entered Upper Activate
value for this setpoint is
subtracted from another (to be
specified) variable.
P5119. AU XXX.XX Activate value upper limit.
Note if P5118 is " % val " or is
" diff " then this value is a
percentage of or difference of
another value
