GSE 574 - Chapter 5 Weighing Mode; 5.1 About The Weighing Mode; 5.2 Weighing Mode (Key Operations)

Model 574 Programmable Counting System (PCS)
48 - GSE Scale Systems
PARAMETER # SELECTION DESCRIPTION
P5120.0 Based Var # Based on one of ten variables,
P80 - P89, which are
accessible during normal
operation
P5120.1 SPt 1 Based on one of setpoint #1's
values
P5120.2 SPt 2 Based on one of setpoint #2's
values
P5120.º SPt32 Based on one of setpoint #32's
values
The set of available choices for P5121 depends upon the selection made in P5120. If set for P5120.0 you will
be able to select from the set immediately below: if set for any other selection, you will be restricted to the
second set of selections below.
P5121.0 Value Var#0 Based on variable #0.
P5121.1 Var#1 Based on variable #1.
P5121.2 Var#2 Based on variable #2.
P5121.9 Var#9 Based on variable #9.
OR
P5121.0 Value AL Based on the lower activation
parameter
P5121.1 AU Based on the upper activation
parameter
P5121.2 DL Based on the lower de-
activation parameter
P5121.3 DU Based on the lower de-
activation parameter
P5130.0 DeAct Above Output de-active if wt. above
target value.
P5130.1 * Below Output de-active if wt. below
target value.
P5130.2 Betwn Output de-active if wt. between
target values.
P5130.3 Outsd Output de-active if wt. not
between target values.
P5130.4 Tare Output de-active if < TARE >
key executed.
P5130.5 Zero Output de-active if < ZERO >
key executed.
