GW Instek PSU Series Programming Manual

REMOTE CONTROL
145
Operation Status Register Group
Overview
The Operation Status Register Group indicates the
operating status of the power supply.
CAL
LOCK
Not Used
OUTP
RMT
WTG
Not Used
Not Used
CV
CP
CC
OND
OFD
Not Used
PR
Not Used
Condition
0
PTR/NTP Event Enable
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Operation Status Register
&
&
&
&
&
&
&
&
&
&
&
&
&
&
&
&
Logical OR
To Status Byte Register
STATus:OPERation:CONDition? STATus:OPERation:EVENt?
STATus:OPERation:NTRansition <NRf>
STATus:OPERation:NTRansition?
STATus:OPERation:PTRansition <NRf>
STATus:OPERation:PTRansition?
STATus:OPERation:ENABle <NRf>
STATus:OPERation:ENABle?
Bit Summary
Event
Bit #
Bit Weight
CAL (Calibration mode)
Indicates if the PSU is in
calibration mode.
0
1
LOCK (Lock State)
Indicates if the PSU is in lock
mode.
1
2
OUTP (Output State)
Indicates the output status of
PSU.
3
8
RMT (Output State)
Indicates if the PSU is in remote
mode.
4
16
