PSU Series Programming Manual
146
WTG (Waiting for trigger)
Indicates if the PSU is waiting for
a trigger.
5
32
CV (Constant voltage mode)
Indicates if the PSU is in CV
mode.
8
256
CP (Constant power mode)
Indicates if the PSU is in CP
mode.
9
512
CC (Constant current mode)
Indicates if the PSU is in CC
mode.
10
1024
OND (Output ON Delay)
Indicates if Output ON delay time
is active
11
2048
OFD (Output OFF Delay)
Indicates if Output OFF delay
time is active
12
4096
PR (Program Running)
Indicates if a Test is running
14
16384
Condition
Register
The Operation Status Condition Register indicates
the operating status of the power supply. If a bit is
set in the Condition register, it indicates that the
event is true. Reading the condition register does
not change the state of the condition register.
PTR/NTR Filters
The PTR/NTR (Positive/Negative transition)
register determines the type of transition
conditions that will set the corresponding bit in the
Event Registers. Use the Positive transition filter to
view events that change from false to positive, and
use the negative transition filter to view events
that change from positive to negative.
