Hakko Electronics Monitouch V7 - Page 164

4
1. Ethernet 4-13
Network Communications
• When communicating with multiple PLCs (same model) on the Ethernet, select
[1 : n] for [Connection] on the [Detail] tab window.
Set the port number (network table number) of the PLC in the [Memory Input] dialog
for each part. For more information on the network table, refer to page 4-14.
[Edit Network Table]
[Memory Input]
