HIKVISION iDS-9000HQHI-M8/S Series - Configure TCP;IP

1.2 Congure TCP/IP
TCP/IP must be properly congured before operang your device over a network. Both IPv4 and
IPv6 are available.
Steps
1.
Go to System → Network → TCP/IP .
Figure 1-8 TCP/IP Sengs
2.
Select Working Mode as Net-Fault Tolerance or Mul-Address Mode.
Net-Fault Tolerance
The two NIC cards use the same IP address, and you can select the main NIC to LAN1 or LAN2.
In this way, in case of one NIC card failure, the device will
automacally enable another
standby NIC card so as to ensure the normal running of the system.
Mul-Address Mode
The parameters of the two NIC cards can be congured independently. You can select LAN1
or LAN2 under Select NIC for parameter sengs. Select one NIC card as the default route.
When the system connects with the extranet, the data will be forwarded through the default
route.
3.
Click IPv4 or IPv6 as you required.
Digital Video Recorder User Manual
8
