5.4.4 Region Exing Detecon
Region exing detecon detects objects that exit from a predened virtual region.
Steps
1.
Go to Smart Analysis → Smart Event Sengs → Perimeter Protecon .
2.
Click Region
Exing.
Figure 5-9 Region Exing Detecon
3.
Select a camera.
4.
Check Enable Region
Exing Detecon.
5.
Follow these steps to set the detecon rules and detecon areas.
1) Select Arming Area. Up to 4 regions are selectable.
2) Set
Sensivity. The higher the value is, the more easily the detecon alarm will be triggered.
Its range is [0-100].
3) Check Target
Detecon as Human or Vehicle. Only the target of selected type will trigger the
alarm.
4) Click Draw Area and draw a quadrilateral in the preview window.
5) Set the Max. Size and Min. Size for valid target object size. Targets smaller or larger than the
valid target size will not trigger
detecon.
6.
Set the arming schedule. Refer to Congure Arming Schedule .
7.
Set linkage
acons. Refer to Congure Linkage Acons .
8.
Click Apply.
