5.
Set the arming schedule. Refer to Congure Arming Schedule .
6.
Set linkage acons. Refer to Congure Linkage Acons .
7.
Click Apply.
5.4.3 Region Entrance Detecon
Region entrance detecon detects objects that enter a predened virtual region.
Steps
1.
Go to Smart Analysis → Smart Event Sengs → Perimeter Protecon .
2.
Click Region Entrance.
Figure 5-8 Region Entrance Detecon
3.
Select a camera.
4.
Check Enable Region Entrance Detecon.
5.
Set
detecon rules and detecon areas.
1) Select Arming Area. Up to 4 regions are selectable.
2) Set
Sensivity. The higher the value is, the easier the detecon alarm will be triggered. Its
range is [0-100].
3) Check Target
Detecon as Human or Vehicle. Only the target of selected type will trigger the
alarm.
4) Click Draw Area, and draw a quadrilateral in the preview window.
5) Set the Max. Size and Min. Size for valid target object size. Targets smaller or larger than the
valid target size will not trigger
detecon.
6.
Set the arming schedule. Refer to Congure Arming Schedule .
7.
Set linkage acons. Refer to Congure Linkage Acons .
8.
Click Apply.
Digital Video Recorder User Manual
72
