1
2
Select [Pos (Position)] from [Type]
of the display range.
3 Select the magnification.
Setting options (∗. default setting)
4 Set the desired zero position as a percent-
age of screen height.
Setting options (default setting: 50%)
x20, x10, x5, x2, x1∗, x1/2, x1/5, x1/10
-50 to 150% (in 1% increments, when the expansion/
compression ratio [Zoom] in the vertical axis (voltage
axis) direction is x1)
In the following steps, use the same operation to con-
figure settings.
The setting can also be
changed on the Waveform
screen. ([Wave+Set] Display)
Change 1's digit
The expansion/compres-
sion range depends on the
selected magnification.
2
3
4
(Open/confirm the setting information.)
Select the [CH] screen.
The voltage range displayed on the Waveform screen varies depending on the zero po-
sition and expansion/compression ratio of the vertical axis, but the measurement range
does not change.
0 V
Zero Position: 0%
50%
100%
(Magnification: x1)
Measure-
ment range
Display range
0%
50%
100%
50%
100%
0%
0%
100%
50%
Zoom Zero Position Setting Range Zoom Zero Position Setting Range
x1/10 -10 to 100% x2 -150 to 250%
x1/5 -20 to 100% x5 -450 to 550%
x1/2 -50 to 100% x10 -950 to 1050%
x1 -50 to 150% x20 -1950 to 2050%
îš„ Display Magnification and Zero Position Setting Range
To Next Page
