Hioki MEMORY HiCORDER MR8880 User Manual

Appendix 2 List of Default Settings
A8
(*1). High-speed Function, (*2). Real-time Function
 Setting Screen (Scheduling)
z
: Setting available, X: Setting not available
Settings Items Initial settings (*1) (*2)
On/Off
Off
z z
Enable/Disable
Off
(check box)
z z
Type
Off
z z
Conditn.
Current
z z
Strt.Day
Daily
z z
Strt.Day/ Stop Day
(year)
00
z z
Strt.Day/ Stop Day
(day)
01
z z
Strt.Tm./Stop Tm.
(time)
00
z z
 Setting Screen (Graph)
z
: Setting available, X: Setting not available
Setting
Items
Initial settings (*1) (*2)
Single
All channel Gr1
z z
Dual Channel 1 Gr1
Channel 2 Gr2
Channel 3 Gr1
Channel 4 Gr2
z z
Quad Channel 1 Gr1
Channel 2 Gr2
Channel 3 Gr3
Channel 4 Gr4
z z
XY Line
XY Dots
Logic
display
Logic A Off
Logic B Off
z
X
 CH/All CH Screen (channels)
z
: Setting available, X: Setting not available
Setting Items Initial settings (*1) (*2)
Channel
CH1
z z
Range
10mV
z z
Mode
INSTNT
z z
L.P.F.
Off
z z
Coupling
DC
z z
Zoom
X1
z z
Waveform
display position
50%
z z
Waveform
color (analog)
Ch1: red, Ch2: green,
Ch3: yellow, Ch4: pink
Waveform
color (logic)
LOGIC A
Bit1: light blue, Bit2: orange,
Bit3: light green, Bit4: blue
LOGIC B
Bit 1: dark purple,
Bit 2: light purple,
Bit 3: very light purple,
Bit 4: cream
z: Setting available, X: Setting not available
Setting Items Initial settings (*1) (*2)
Logic display
position
Logic A: Pos1
Logic B: Pos2
z z
Logic display
width
Narrow
z z
Monitor display
specification of
Channel Set-
tings screen
All CH
z z
XY display color XY1: red,
XY2: green,
XY3: yellow
XY4: pink
z
X
X-Y plot
X-axis channel
XY1 to 4: CH1
z
X
X-Y plot
Y-axis channel
XY1: CH1,
XY2: CH2,
XY3: CH3,
XY4: CH4
z
X
