Appendix 2 List of Default Settings
A9
Appendix
(*1). High-speed Function, (*2). Real-time Function
 CH/ All CH Screen (Upper/lower limit)
z
: Setting available, X: Setting not available
Setting Items
Initial
settings
(*1) (*2)
Disp Span - Type
Pos
z z
Upper
0.05
z z
Lower
-0.05
z z
 CH/ All CH Screen (Scaling)
z
: Setting available, X: Setting not available
Setting Items
Initial
settings
(*1) (*2)
Scaling
Off
z z
Scaling setting
Ratio
z z
Ratio
1
z z
Offset
0
z z
Voltage coefficient 1
Cnv1 (2-point)
0.05
z z
Voltage coefficient 2
Cnv2 (2-point)
-0.05
z z
Scaling coefficient 1
(Unit1) (2-point)
0.05
z z
Scaling coefficient 2
(Unit2) (2-point)
-0.05
z z
Unit
−
z z
 Comment Screen
z
: Setting available, X: Setting not available
Setting Items
Initial
settings
(*1) (*2)
Title
-
z z
Analog CH1 to CH4
-
z z
Logic LA1 to LB4
-
z z
Print items-Title
Settings
z z
Print items-Analog
Settings
z z
Print items-Logic
Off
z z
 Waveform Screen
z
: Setting available, X: Setting not available
Setting Items Initial settings (*1) (*2)
Screen display
Wave+Set
z z
Gauge
ALL 1
z z
 Wave+Crsr Screen (A/B cursor)
z
: Setting available, X: Setting not available
Setting Items Initial settings (*1) (*2)
Type
Trace
z z
Type (when XY dis-
play)
Trace
z
X
Move
A Cur
z z
A, B: (when XY dis-
play)
XY1
z
X
(*). This setting value is not reset when the instru-
ment is initialized.
 System Screen (Communications)
z
: Setting available, X: Setting not available
Setting Items Initial settings (*1) (*2)
Delimiter
CR+LF (*)
z z
Header
Off (*)
z z
