Hioki MEMORY HiCORDER MR8880 User Manual

Appendix 2 List of Default Settings
A10
(*1). High-speed Function, (*2). Real-time Function
 Trig Screen (Trigger)
z
: Setting available, X: Setting not available
Setting Items
Initial
settings
(*1) (*2)
Trig Func
Off
z z
Timing
Start X
z
Ext trig
(Start)
Off
z z
(Stop)
Off X
z
Filt (filter for external
trigger)
Off
z z
Trigger Condit.(AND/OR)
(Start)
OR
z z
(Stop)
OR X
z
Pre-Trig (%)
0
z
X
(d/h/m/s)
0 X
z
Start trigger
Trigger type
Off
z z
Level
0.0mV
z z
Drop level
40.0mV
z
X
Drop frequency(f)
60Hz
z
X
Trigger slope (S)
↑
z z
Window-In/Out
trigger Level
Upper
20.0mV
Lower
-20.0mV
z z
Trigger filter (Filt)
Off
z z
Judge frequency (f)
60Hz
z
X
Judge Ref
Sine
z
X
Judge Range
±5.0mV
z
X
Judge Ref volt
20.0mVr
z
X
Stop trigger
Trigger type
Off X
z
Trigger level
0.0mV X
z
Trigger slope
↑
X
z
Window trigger Upper
20.0mV
Lower
-20.0mV
X
z
Trigger filter (Filt)
Off X
z
z: Setting available, X: Setting not available
Setting Items
Initial
settings
(*1) (*2)
Logic (Start)
Trigger source
Off
z z
Trigger bit
pattern bit 1- bit 4
X (Off)
z z
Trigger filter
Off
z z
Logic (Stop)
Trigger source
Off X
z
Trigger bit
pattern bit 1- bit 4
X (Off) X
z
Trigger filter
Off
z z
Interval trigger
Off
z z
Interval (Intvl.)
d/h/m/s
0Day
0Hour
0Min
1Sec
z z
