9.4 Configuring the Communications Protocol
102
Set the GP-IB address and message terminator on the System screen.
Configuring GP-IB Interface Communications (RM3542-01 only)
1
Open the Basic Settings screen.
2
Open the System screen.
3
Select the interface type.
4
Select the instrument's address.
5
Select the interface message terminator.
6
Return to the Measurement screen.
The Basic Settings screen appears.
The System screen appears.
[SYSTEM]
1
Selection
2
Selection
2
GP-IB Interface
1
Selection
0 to 30 (default: 1)
1
2
3
Selection
2
LF (default)
CRLF
1
The confirmation screen appears.
Return to the setting screen.
Save setting and return to
previous screen.
Discard setting and return to
previous screen.
“GP-IB” is only displayed on model RM3542-01 (equipped with GP-IB).
To Next Page
