Default Settings
Display Setting value Default Settings Setting Description
MENU
TRG
INT/ EXT/ MANU EXT Trigger source selection (p. 30)
RANGE
/ 
[Low Power: Off] 100m/
1000m/ 10/ 100/ 1000/
10k/ 100k/ 1000k/ 10M/
100M
[Low Power: On] 1000m/ 10/
100/ 1000
100 M Range selection (p. 31)
SPEED
SLOW/ MED/ FAST FAST Measurement speed (p. 29)
0ADJ
OFF/ ON OFF Zero adjustment (p. 32)
COMP
OFF/ ON ON Comparator function(p. 34)
LOCK
OFF/ FULL / MENU OFF Key-Lock function (p. 59)
MISC
MEAS/ DATA/ SYSTEM (Miscellaneous settings)
MISC
MEAS
DELAY1
0 to 100 ms (all ranges) 0 ms Probe delay setting (p. 42)
DELAY2
0 to 100 ms 0 ms DUT response setting (p. 42)
INT (FAST)
0.1 ms to 100 ms
1PLC to 6PLC (60 Hz)
1PLC to 5PLC (50 Hz)
Depends on measurement range Integration time (p. 44)
INT (MED)
INT (SLOW)
CONT CHECK
OFF/ ON
ON, 200  Contact-check (p. 46)
50 / 100 / 150 / 200 / 300
/ 400 / 500 
CONT IMP
OFF/ ON/ PULSE
17 mA/ 25 mA/ 35 mA/ 50 mA
ON, 35 mA (range from 100 m to
100 k)
PULSE, 35 mA (range from1000
k to 100 M)
Contact Improvement (p. 47)
VOLT
MONITOR
OFF/ ON
ON, NORMAL (LOOSE when
100 Range)
Voltage level monitor (p. 49)
LOOSE/ NORMAL/ SEVERE
CURRENT
MODE
CONT/ PULSE PULSE Current mode setting (p. 50)
DATA
AUTO MEMO-
RY
OFF/ ON OFF Auto-Memory function (p. 71)
STATISTICS
OFF/ ON OFF
Statistical calculation function
(p. 74)
DATA OUT
OFF/ ON OFF Data output function (p. 77)
SYS-
TEM
SET MONITOR
OFF/ ON,
1st/ 2nd, 0.000% to 9.999%
OFF, 1st, 0.000% Settings Monitor function (p. 53)
PROBE
CHECK
OFF/ ON, 0 to 100 ms OFF, 5 ms Probe short-circuit detection (p. 51)
RETRY
OFF/ ON, 1 to 50 ms ON, 50 ms Retry function (p. 56)
TRIG EDGE
OFF EDGE/ ON EDGE ON EDGE Start Logic Setting (p. 94)
EOM
PULSE/ HOLD
1 to 100 ms
PULSE, 5 ms
End-of-measurement pulse width
(p. 93)
INTERFACE
GP-IB/ RS232C/ PRINT
RS232C, 9600bps
GP-IB, ADR01, LF
Interface setting (p. 101)
LOW POWER
OFF/ ON OFF
Low-Power Resistance Measure-
ment (p. 28)
JUDGE BEEP
OFF/ ON
IN/ HI/LO/ LOW/ HIGH
OFF, HI/LO Comparator decision beeper (p. 61)
KEY BEEP
OFF/ ON ON Key beeper (p. 59)
CLOCK
Clock setting (p. 64)
LINE FREQ
AUTO/ 50 Hz/ 60 Hz AUTO Line frequency (detection) (p. 63)
CONTRAST
0 to 100 50 Screen contrast adjustment (p. 65)
BACK LIGHT
0 to 100 80 Screen backlight adjustment (p. 66)
RESET
- - Reset (p. 67)
ADJUST
- - Calibration (p. A13)
