Hioki RM3542 - Chapter 3 Measurement Settings (Basic Measurements); 3.1 Pre-Operation Inspection

21
2
Be sure to read the "Operating Precautions" (p.7) before installing and connecting this instrument.
Refer to "Appendix 4 Rack Mounting" (p. A8) for rack mounting.
Measurement
Preparations Chapter 2
Install this instrument (p. 7)
1
Rear PaneFront Panel
Connect measurement cables
(p. 23)
Turn the power on (p. 25)
5
Connect to the test sample
When finished measuring, turn the
power off (p. 25).
Connect the external interface
(as needed)
4
• Using the printer (p. 79)
• Using the RS-232C or GP-IB interface
(p. 97)
• Connecting to a PLC or I/O board
(p. 85)
• Automatically comparing the settings
of two instruments (Settings Monitor
function) (p. 53)
Connect the power cord (p. 22)
2
3
2
3
4
5
Make instrument settings (p. 27)
6
