Hioki RM3542 - With the ADEX AX-162 D

Appendix 8 Table of Commands Compatible with the ADEX AX-162D
A15
Appendix
Example 1
Measurement mode: R mode
Measurement range:10 
Upper limit: 1.900 
Lower limit: 1.100 
Measurement speed: SLOW
Trigger after the above settings
Example 2
Measurement mode: % mode
Reference resistance: 100 k(Measurement range:100 k)
Upper limit: 10.00%
Lower limit: -10.00%
Measurement speed: FAST
Trigger after the above settings
AX-162D (Original mode) RM3542
M1 :CALCulate:LIMit:MODE ABS
RNG2 :RESistance:RANGe 10
LH1900E-3 :CALCulate:LIMit:ABS 1900E-3,1100E-3
LL1100E-3
S0 :SPEEd SLOW
E *TRG
or
M1RNG2LH1900E-3LL1100E-3S0E
Note: Although no delimiters are shown, they must be included at the end of each command line.
AX-162D (Original mode) RM3542
M0 :CALCulate:LIMit:MODE REF
:RESistance:RANGe 100E+3
RS100E+3 :CALCulate:LIMit:REFerence 100E+3
LH+1000E-2 :CALCulate:LIMit:PERCent +1000E-2,-1000E-2
LL-1000E-2
S1 :SPEEd FAST
E *TRG
or
M0RS100E+3LH+1000E-2LL-1000E-2S1E
Note:
Although no delimiters are shown, they must be included at the end of each command line.
Even when the reference standard resistance is set on the RM3542, the range is not automatically selected.
Use the range setting command to set the same value as the reference standard resistance. When setting
the same value as the reference standard using the range setting command, there are cases where the
range is different from the RM3542’s auto-ranging selection, depending on the value.
