7.1 Connecting the Printer
79
7
Before connecting the printer
Compatible printer
The requirements for a printer to be connected to the instrument are as follows.
Confirm compatibility and make the appropriate settings on the printer before connecting it to
the instrument.
See: "7.2 Instrument Settings" (p. 81)
• Interface ................................ RS-232C
• Characters per line................ At least 45
• Communication speed........... 9600 bps
• Data bits ................................ 8
• Parity ..................................... none
• Stop bits................................. 1
• Flow control........................... none
Printing Chapter 7
Printing (p. 82)
• Measurement values and
comparator decisions
• Statistical calculation
results
Connecting the printer to
the instrument
Make instrument
settings (p. 81)
Make printer
settings
7.1 Connecting the Printer
Because electric shock and instrument damage hazards are present, always follow
the steps below when connecting the printer.
• Always turn off the instrument and the printer before connecting.
• A serious hazard can occur if a wire becomes dislocated and contacts another con-
ductor during operation. Make certain connections are secure.
• As much as possible, avoid printing in hot and humid environments. Otherwise, printer life
may be severely shortened.
• Use only compatible recording paper in the printer. Using non-specified paper may not only
result in faulty printing, but printing may become impossible.
• If the recording paper is skewed on the roller, paper jams may result.
