11.3 Error Displays and Remedies
181
11
The following messages are displayed when the instrument detects an error or abnormal measurement set-
ting. If repair is necessary, contact your dealer or Hioki representative.
11.3 Error Displays and Remedies
Display Description Remedy
+OvrRng/-OvrRng Measurement out of range (p. 38) Select the appropriate range.
C.E. Hi Hi wiring contact error (p. 38)
Check for cable breakage and worn
out probes.
C.E. Lo Lo wiring contact error (p. 38)
Check for cable breakage and worn
out probes.
C.E. Volt
Voltage Level Monitor error
(p. 38)
Check for worn out probes.
ERR:001
LOW limit is higher than UPP
limit
Upper limit is below lower limit Check comparator settings (p. 34).
ERR:002
[when LP resistance mea-
surement is disabled]
Exceeding range (From 0
 to
120M)
[when LP resistance mea-
surement is enabled]
Exceeding range (From 0
 to
1200)
Comparator input is out of range.
(out-of-range reference value,
such as 1000 M
)
Check comparator settings (p. 34).
ERR:003
Setting monitor error.
(COMP)
Comparator settings are different
from the other RM3542.
Make comparator settings the same
(p. 53).
ERR:004
Setting monitor error.
(SPEED)
SPEED setting is different from
the other RM3542.
Make SPEED settings the same
(p. 53).
ERR:011
Zero adjustment error. Offset
value exceeds 10.
Out of zero-adjust range
Check the zero-adjustment proce-
dure (p. 32).
ERR:021 Probe short error Short-circuited probe
Check for correct connections
(p. 51).
ERR:031 Command error Command Error
Check for incorrect commands
(p. 115).
ERR:032 Execution error Execution Error
Check the last command and instru-
ment state (p. 115).
ERR:033
RS-232C communication
error
I/F Communications Error
Check communication settings and
wiring.
ERR:034
Setting monitor communica-
tion error
Settings monitor communications
error
Check settings monitor settings and
wiring (p. 53).
ERR:041
Line frequency detection
error
Error detecting the line frequency
Manually set the frequency to match
the line (p. 63).
ERR:042
Clock error
Reset?(09-01-01 00:00:00)
Press F1 Key.
The clock is not set, so pressing
F1 [OK] displays the initialized
time 09-01-01 00:00:00.
The back-up battery needs to be re-
placed. Contact your nearest Hioki
representative.
ERR:101
Hardware error
(Main CPU ROM)
Hardware failure. Repair is required.
ERR:102
Hardware error
(Main CPU RAM)
Hardware failure. Repair is required.
ERR:103 Hardware error (SRAM) Hardware failure. Repair is required.
ERR:104
Hardware error
(Adjustment data)
Hardware failure. Repair is required.
ERR:105
Hardware error
(Backup data)
Reset? Press F1 Key.
Hardware failure. (back-up data is
corrupted)
Repair is required.
Press F1 [OK] to resets the instru-
ment.
