9.9 Sample Programs
157
9
 External Trigger Measurement 1
Measure and import according to external triggering of the RM3542 (F4 [MANU] key or TRIG signal input),
and save measurements in a text file.
Private Sub MeasureTrigSub()
Dim buffer As String 20 'Receiving buffer
Dim recvstr As String 'Receiving char string
Dim pad As Integer 'Controller Address
Dim gpibad As Integer 'Device Address
Dim timeout As Integer 'Timeout period
Dim ud As Integer 'State (unused)
Dim i As Integer
pad = 0 'Board Address 0
gpibad = 1 'RM3542 Address 1
timeout = T100s 'Timeout 100s (because of external trigger wait state)
Call ibfind("gpib0", 0) 'Initialize GP-IB
Call ibdev(pad, gpibad, 0, timeout, 1, 0, ud)
Call SendIFC(pad)
Open App.Path & "\data.csv" For Output As #1 'Open a text file for saving
Call Send(pad, gpibad, ":TRIG:SOUR EXT", NLend) 'Select external triggering
Call Send(pad, gpibad, ":INIT:CONT OFF", NLend) 'Continuous measurement OFF
For i = 1 To 10
Call Send(pad, gpibad, ":READ?", NLend) 'Send ":READ?" to measure and import the
measurement
Call Receive(pad, gpibad, buffer, STOPend) 'Receive
recvstr = Left(buffer, InStr(1, buffer, Chr(10)) - 1)
Print #1, Str(i) & "," & recvstr 'Write to the file
Next
Close #1
Call ibonl(pad, 0)
End Sub
