Chapter 10 Specifications
168
(2) Range Switching
(3) Low-Power Function
(4) Delay Setting
ABS Mode
Upper/Lower limit ranges 0.00 m to 120.00 M (LOW POWER OFF)
0.0 m to 1200.0 (LOW POWER ON)
Comparator On Per following table
Table 1. Ranges of reference (REF%) tolerance and upper limit (ABS) values
Manual setting is available on the Basic Settings screen.
Comparator Off The range is selected by Range key
Default setting 100 M
Low Power OFF Low Power ON
Range of reference (REF%)
and upper limit (ABS)
values
Selected Range
Range of reference (REF%)
and upper limit (ABS)
values
Selected Range
0 to 100.09 m 100 m  
100.1 to 1000.9 m 1000 m 0 to 1000.9 m 1000 m
1.001 to 10.009  10  1.001 to 10.009  10 
10.01 to 100.09  100  10.01 to 100.09  100 
100.1 to 1000.9  1000  100.1 to 1200.0  1000 
1.001 to 10.009 k 10 k  
10.01 to 100.09 k 100 k  
100.1 to 1000.9 k 1000 k  
1.001 to 10.009 M 10 M  
10.01 to 120.00 M 100 M  
Operation Changes resistance measurement current (setting affects all ranges)
Default state Low Power OFF
Setting ON/ OFF
DELAY1
Operation Adjusts the mechanical delay of trigger input and probing (setting affects all ranges)
Default state 0.0 ms
Setting range 0.0 ms to 100.0 ms
DELAY2
Operation Adjusts measurement object response (for each range)
Default state 0.0 ms
Setting range 0.0 ms to 100.0 ms
