3.7 Judging Measured Values (Comparator Function)
36
2
Set the reference value.
Pressing an inoperative key during setting sounds a low-pitch beep (when the key beeper is enabled).
Press the units key to accept the setting and move the cursor to the positive tolerance.
3
Set the positive tolerance.
Press the % key to accept the setting and move the cursor to the negative tolerance value.
The negative tolerance is initially set to the same amplitude as the positive tolerance (change as needed).
4
Set the negative tolerance in the same way (as needed).
5
Accept the settings and return to the Measurement screen.
Selection
1
To Reset Numerical Values
Deletes entered digits.
This key is enabled only when en-
tering numerical values.
To change the value after selecting the
units, use the cursor keys to select
the item to change, then enter the new val-
ue with the tenkeys.
1_ 10_ 10._ 10.5_ 10.50 
(Example: 10.5)
2
Selection
To Reset Numerical Values
Deletes entered digits.
This key is enabled only when enter-
ing numerical values.
To change the value after selecting the
units, use the cursor keys to select
the item to change, then enter the new val-
ue with the tenkeys.
To Set a Negative Value
Press this key to change the sign,
as needed.
1
+4_ +4._ +4.5_ +4.500%
(Example: 4.5%)
2
Selection
• Internal calculations are performed on floating-point values, and decisions round up any fraction of the
least-significant digit.
• Displayed values of the reference and tolerances are rounded according to the selected range. Internal
calculations use unrounded data, so decisions are based on the entered (setting) values.
• An error message appears if you press ENTER with the positive tolerance set lower than the negative
tolerance.
See: "11.3 Error Displays and Remedies" (p. 181) (ERR:001)
