4.2 Setting Pre-Measurement Delay
43
4
Determining the Delay Time
Set the delay so that inductance does not affect measurements.
To fine tune the delay, begin with a longer delay than necessary, then gradually shorten it while watching the
measured value.
1
Open the Basic Settings screen.
2
Open the Measurement Settings Screen.
3
Set DELAY1 or DELAY2.
4
Return to the Measurement screen.
The Basic Settings screen appears.
The Measurement Settings Screen
appears.
[MEAS SETTINGS]
1
2
Selection
1
2
Setting range: 0.0 ms (default) to 100.0 ms
DELAY1 is common to all ranges, while
DELAY2 can be set for each range inde-
pendently (p. 41).
Tenkeys
3
Selection
The confirmation screen appears.
Return to the setting screen.
Save setting and return to
previous screen.
Discard setting and return to
previous screen.
