Hisun HS200UTV - Page 166

-151-
ENGINE
- 151 -
No. Part Name Qty Remarks
11
Cover seat comp clutch
1
12
Piled head clutch cover
1
13
Rubber sheath
1
14
Primary clutch component
1
15
Bush Φ32×40
1
16
O-ring 20.7×2.6
1
17
Flange bolt M6×25
3
18 Bush Φ6.5×5 3
For assembly, reverse the disassembly
procedure.
