Hisun HS200UTV - Direction System

-177-
CHASSIS
- 177-
DIRECTION SYSTEM
Steering Wheel part
No. Part Name Qty Remarks
Removing the steering wheel
1
Steering wheel body 1
2
Decoration cover for steering wheel 1
3
Horn assembly 1
4
Hexagon socket head screw M6×16 6
5
Screw M5×16 1
6
Steering column 1
7
Nut M12×1.25 1
8
Nylon bushing II 2
9 Hex flange step bolt M8×13-Φ12×12 2
