No. Part Name Qty Remarks
10 Hexagon flange self-locked nut M8 2
11 Hexagon flange bolt M8×16 1
12 Ignition switch assy. 1
13 Steering joint 1
14 H-shaped rubber ring 1
15
Hexagon flange self-locked nut M8×30
3
16 Washer Φ8×Φ16×1.6 3
17 Split washer-8 3
18 Ignition switch upper cover 1
19 Ignition switch lower cover 1
20
Cross small plate head tapping screw ST3.9×25
4
CHASSIS
- 179-
No. Part Name Qty Remarks
21
Socket hexagon flat head screws M6×16
2
22 Passenger handle bar assy. 1
23 Handle bar locating seat 1
24 Handle bar grip 2
25 Hexagon flange bolt M8×35 1
26 Hexagon flange self-locked nut M8 1
