-179-
CHASSIS
- 179-
No. Part
Name Qty
Remarks
21
Socket hexagon flat head sc
rews M6×16
2
22
Passenger handle bar assy
.
1
23
Handle bar locating seat
1
24
Handle bar grip
2
25
Hexagon flange bolt M8×35
1
26
Hexagon flange self-locked nut M8
1
