-180-
CHASSIS
- 180-
No. Part Name Qty Remarks
1 Steering assembly 1
2 Steering mechanism upper cover 1
3 Steering mechanism base 1
4 Steering mechanism shaft I 1
5 Steering mechanism shaft II 1
6
Paper gasket，steering mechanism
1
7
Gear，steering mechanism
1
8 Locating Sleeve 2
9 Bearing 6003-2RZ 1
10 Bearing 6004-2RZ 1
CHASSIS
- 181-
No. Part Name Qty Remarks
11 Bearing 6202-2RZ 1
12 Bearing 6300-2RZ 1
13 Oil seal Φ34×Φ20×7 1
14 Oil seal Φ34×Φ17×5 1
15 Hexagon socket head bolt M6×40 5
16 Bolt M10×1.25×22 3
