-181-

CHASSIS

- 181-

No. Part Name Qty Remarks

11 Bearing 6202-2RZ 1

12 Bearing 6300-2RZ 1

13 Oil seal Φ34×Φ20×7 1

14 Oil seal Φ34×Φ17×5 1

15 Hexagon socket head bolt M6×40 5

16 Bolt M10×1.25×22 3
