Figure 5-163 Removing a power supply dummy module
Installing any dummy module
1. Put on an anti-static wrist strap.
2. Reverse the removal procedure.
Replacing a shelf in the server chassis
This procedure describes how to replace a shelf. The shelf is hot-swappable
component and allows shelf replacement with the server chassis power on.
Removing a shelf for half-wide server blade
1. Put on an anti-static wrist strap.
2. Pull out the shelf while releasing the both lock as shown below.
Figure 5-164 Removing a shelf for half-wide server blade
Replacing parts
5-129
Hitachi Compute Blade 500 Series System Service Manual
