Figure 5-71 Removing the USB
Installing a USB
1. Put on an anti-static wrist strap.
2. Reverse the removal procedure.
Removing a USB enablement kit
1. Put on an anti-static wrist strap.
2. Remove the target server blade. See Removing a half-wide server blade
on page 5-4 section.
3. Open the top cover of the server blade. See Opening a top cover, Server
blade on page 5-38 section.
4. Pull up the air duct portion of the USB enablement kit and remove it.
Replacing parts
5-57
Hitachi Compute Blade 500 Series System Service Manual
