Hitachi CB 520H A1 Service Manual

Updating BMC/EFI firmware on server blade
Tip: Before performing the following procedures, you must download the
updated firmware file from Hitachi Data System support portal to the console
PC.
1. [For CB 520A A1, CB 520H A1/B1/B2/B3/B4, CB 540A A1/B1, and Non-
SMP CB 520X B1/B2/B3]
Select Resources tab and select Modules > Server Blades > a target
blade that should update the firmware.
[For SMP CB 520X B1/B2/B3]
Select Resources tab and select Modules > Server Blades > Server
Blade n of the SMP configuration > a target blade that should
update the firmware.
2. Select Condition tab.
3. Click Action and then select Update Firmware.
4. The update dialog box is displayed. Click Browse and select the new
firmware file.
5. Click Confirm.
Figure 9-1 Select the updated firmware
6. The confirmation dialog box appears. Click OK and then firmware update
will start.
7. After the firmware update process has completed, the successful message
dialog box appears. Click Close.
9-2
Updating firmware
Hitachi Compute Blade 500 Series System Service Manual

Hitachi CB 520H A1 Specifications

General

Brand	Hitachi
Model	CB 520H A1
Category	Server
Language	English
