4-2
4.1.2 Approach to the parts on the front side of the equipment
１ Move the ink tank and the makeup ink tank to a safe place after
removing the connection tube block.
２ Remove the ink filter from the fixture and draw it out.
３ Remove the fixing screws (2 pieces) of the tank base plate and remove
the tank base.
Ink reservoir
Makeup ink reservoir
Connection tube block
Connection tube block
Tank base
Fixing screw
