Honeywell IP-AK2 User Manual

Honeywell
2 Introduction
The IP-AK2 Access Control Unit is one part of Access Control System (see Figure 4-1
IP-AK2 Panel Connections in IP-AK2 Access Control System
on page 14), which
protects and preserves enterprise’s resources by providing authentication, authorization,
and administration services.
The IP-AK2 Access Control Unit consists of:
• An IP-AK2 Access Control Panel
• A Power Supply
• A Sealed Lead-acid Battery
The following figure shows the IP-AK2 Access Control Unit components in the cabinet.
Figure 2-1 IP-AK2 Access Control Unit
POWER SUPPLY
BATTERY
LED
220VAC Power Input
Backup power loss
alarm input
Indictor LED
connected 12VDC
RS232
Host 485
Reserved
Ethernet
Panel Tamper
Contact
Reader1
Reader2
Relay 1, 2 Relay 3, 4
Chassis Ground
Connected Cable
SVS input
3

Honeywell IP-AK2 Specifications

General

Brand	Honeywell
Model	IP-AK2
Category	Switch
Language	English
