The wire used for the inputs should be shielded and cannot exceed 20 ohms over the
entire length of the cable. Remember that the distance from the panel to the door must
be doubled to determine the total resistance.
Caution
The cable shield should be grounded only at the panel. Grounding at both ends
can cause ground loops disruptive.
Output Wiring
Relay 1 is defaulted for controlling Door 1 lock, Relay 2 is defaulted for controlling Door 2
lock, Relay 3 and Relay 4 are used as auxiliary outputs.
IP-AK2 panel is connected to the nominal 12VDC power supply and cannot be used to
power the access control door strikes/locks or other auxiliary loads. The voltage range of
the relay outputs is 12VDC to 28VDC.
Each relay also has a green indicator LED, which indicates the relay state. If the relay is
triggered, the LED will be on.
Caution
The cable used must be sized for the current load and should be shielded. Do
not bundle these wires with communication, reader, or supervised input wiring.
DIP Switch Settings
IP-AK2 panel includes 10 DIP switches. The table below shows DIP Switch Definition.
Table 3-4 DIP Switch Definition
DIP Switches State Definition
1-5 Panel Address (1 ~ 31)
6 ON/OFF Master/Slave
ON OFF Default IP and User
OFF ON Factory Default
ON ON Reserved
7-8
OFF OFF Normal Operation
9-10 Host 485 EOL
Position 1 to position 5, whose panel address from 1 to 31; they are must not been set 0,
which is invalid.
Position 6 will be set with the Host RS485 Master & Slave mode. For Multidrop RS-485
line, Position 6 MUST be set “ON” for RS-485 gateway in Master mode.
Position 7 and position 8 have four combinations. When both of them are “OFF”, it
means normal operation; When position 7 is “ON” and position 8 is “OFF”, it means the
11
