Figure 3-3 IP-AK2 Panel Cabinet - Left View
78mm [3.071”]
30mm [1.181”]
0mm [0.000”]
0mm [0.000”]
55mm [2.165”]
φ30mm [φ1.181”] Diameter Knockout
195mm [7.677”]
340mm [13.386”]
Figure 3-4 IP-AK2 Panel Cabinet - Right View
30mm [1.181”]
78mm [3.071”]
0mm [0.000”]
0mm [0.000”]
55mm [2.165”]
φ30mm [φ1.181”] Diameter Knockout
195mm [7.677”]
340mm [13.386”]
