Honeywell
Setting Description
Card Holder Name
Identifies the card holder. A card holder’s name includes first name
and last name. Each name supports up to 25 characters.
Card Type
Specifies whether the card holder is an employee, VIP, or a
temporary employee (Temp). A card type is required.
Activation
Specifies the date that a temp card is activated. Note that this field is
active only when the Card Type is set to Temp.
Expiration
Specifies the date that a temp card is de-activated. Note that this field
is active only when the Card Type is set to Temp.
PIN
Specifies the Personal Identification Number (PIN) for the card
holder. A PIN is optional; however, if the door reader is configured to
require PIN identification, then you must create a PIN for the card
holder here.
The PIN number has a maximum of six digits.
NO. of uses
Specifies the number of times the card can be successfully treated as
valid on a panel.
Pin Not Required
If it’s checked, the card will be granted access without input PIN code
even if PIN is required in reader mode.
Access Level
Specifies the time zone, or time schedule, during which the card
holder can be granted access at specific doors. Up to 32 access
levels can be supported by one card.
Trace
Sends an alarm message to the alarm monitor whenever a card with
trace enabled is presented at a reader. This feature provides a trace
of the cardholder’s path through the facility.
3. Click【OK】.
Modifying Card
1. Click the name of a card to be modified to select it, and click【Edit Card】below
the list to open the page below:
Figure 5-46 Modify Card
2. Change card properties.
3. Click【OK】to accept changes.
Deleting Card
1. Click the name of a card to select it.
2. Click【Delete Card】below the list.
39
